NC Straight Cutting and Punching Machine

Name: NC Straight Cutting and Punching Machine
Brand: CANGZHOU KENUO INTERNATIONAL CO., LTD.
Price: 10000 USD
Availability: InStock

Price 10000 USD ($)/ Unit

Get a Price/Quote

MOQ : 1 Unit

NC Straight Cutting and Punching Machine Specification

Drive Motor
Hydraulic Motor

Product Type
Metal Cutting Machine

General Use
Sheet Metal Fabrication

Material
Sheet Metal, Stainless Steel

Type
NC Cutting and Punching Machine

Capacity
Up to 15 Ton/Day

Weight (kg)
2750 kg

Computerized
Yes

Automatic
Yes

Cutting Speed
10-18 m/min

Cutting Thickness
Up to 8 mm

Cutting Function
Straight Cutting and Punching

Cooling System
Forced Air Cooling

Drive Type
Hydraulic

Voltage
380V / 415V

Dimension (L*W*H)
3200 x 1700 x 1700 mm

Feature
High Precision, Automatic Operation

Color
Industrial Grey

Motor
Powerful Servo Motor, 7.5 kW

Mechanical Precision
0.1 mm

Software Detail
NC Controller Panel

Cutting Method
Straight Shear

Control System
NC + PLC

Cutting Material
Steel, Stainless Steel, Aluminum

Cutting Area
1250 x 2500 mm

Operation Mode
Fully Automatic, Manual Optional

Noise Level
75 dB

Power Consumption
8 kW

Maximum Punching Force
300 kN

Display Type
Digital Touch Panel

Back Gauge Range
800 mm

Working Environment Temperature
045C

Oil Tank Capacity
200 Liters

Max. Stroke per Minute
35

Installation
Floor Mounted

Safety System
Emergency Stop, Safety Guarded Doors

NC Straight Cutting and Punching Machine Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
60 Days

About NC Straight Cutting and Punching Machine

We are a leading manufacturer and exporter of hi-tech range of NC Straight Cutting and Punching Machine in Cangzhou. China. We independently carry out the designing and developing work and offer patented designs to our customers. This type of machine is used in industrial applications of cutting and punching metal sheets, silicon steel sheet, using numeric control. We are proud to develop an array of NC Straight Cutting and Punching Machine, which is known for excellent designs and high performance. Customers willing to purchase may contact us.

Features:

Innovative designs
Excellent performance
Long lasting and reliable
Cost-effective

Model:HJ-2002/3002/5002-S

Introduction and Usage

This machine is mainly used for straight cutting&punching
silicon steel lamination for transformer or reactors automatically.
Cut the silicon steel to be kinds of shape,such as right angle,bevel angle,
Straight angle& bevel angle,punched,punched V shape etc.
This machine also has step-lap function.

Specification

Cutting length:1-99999mm
Cut-to-length precision:+-0.02mm
Cutting angle precision: Max 0.025degree
Cutting burr height:Max0.02mm
Punching burr height:Max0.03mm
Punching hole numbers:1-12
Cutting speed:1-140 pieces per minute

Characteristics

Cutting power: Support the inverter motors of domestic famed brands, incorporate advanced speed, cut down the noise, extended service life.
Feeding power: Appoint big torque AC servo motors, fast response, high and valuable positioning, low tumult, small thermal decline, durable life.
Rail positioning: Step motor drings, central locations, ball screws & linear guide consignment, speedy and precious.
Motion control: The motion control is executed by advanced PLC, HMI (Human Machine Interface) operation, effortless, convenient and adaptable maintenance.
Lamination collecting: Circulating bells plus unloaded racks.
Life assurance: The imported and worlds' most popular linear guides, ball screws, highly precious milling components are provided, advanced and precised assembly, enhanced service lives of the machines.

Precision Engineering for High Output

This NC Straight Cutting and Punching Machine delivers unmatched mechanical precision at 0.1 mm, ensuring every sheet is processed to the highest standard. Its fully automated system, supported by NC + PLC control, streamlines operations while minimizing human error and maximizing throughput up to 15 tons per day.

User-Friendly Digital Interface

The intuitive digital touch panel display allows operators to manage settings and monitor production in real time. Whether running in automatic mode or switching to manual operation, adjustments are straightforward, making the machine accessible to experienced technicians and new users alike.

Safety Meets Productivity

Built with safety as a priority, the machine features emergency stop functions and safety-guarded doors, ensuring operator protection without compromising processing speed or efficiency. Its robust forced air cooling system maintains stable performance during extended operation hours.

FAQs of NC Straight Cutting and Punching Machine:

Q: How does the NC Straight Cutting and Punching Machine operate?

A: The machine operates using a fully automatic NC controller paired with a PLC system, allowing for precise straight cutting and punching of sheet metals. Operators set parameters via the digital touch panel, and the servo and hydraulic motors manage the cutting and punching process efficiently.

Q: What materials and thicknesses can this machine handle?

A: This machine is capable of processing steel, stainless steel, and aluminum sheets with a cutting thickness of up to 8 mm, making it suitable for various sheet metal fabrication applications.

Q: When is manual operation required or beneficial?

A: Manual operation is available as an option for tasks requiring more operator control or during setup and calibration processes. This feature provides additional flexibility for custom or low-volume jobs.

Q: Where should the machine be installed for optimal performance?

A: The machine is designed for indoor, floor-mounted installation in industrial environments. It performs optimally within a working temperature range of 045C, with sufficient space to accommodate its 3200 x 1700 x 1700 mm dimensions.

Q: What is the process for straight cutting and punching?

A: The process begins with loading the sheet metal onto the worktable. Using the NC controller, operators configure cutting and punching parameters. The hydraulic drive system then performs the required operations at speeds of 1018 m/min, with up to 35 strokes per minute.

Q: How does the safety system enhance operator protection?

A: The safety system includes emergency stop buttons and safety-guarded doors that immediately halt machine operation if triggered, safeguarding operators and maintenance staff during use.

Q: What benefits does this machine offer for sheet metal fabrication units?

A: Key benefits include high mechanical precision, robust daily capacity (up to 15 tons), automated operation reducing labor, minimal noise levels, advanced safety features, and easy integration into mass production lines, improving both efficiency and quality in fabrication processes.
